Asus RT-AX89X

Model Name

RT-AX89X

Network Standard

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

IEEE 802.11n

IEEE 802.11ac

IEEE 802.11ax

IPv4

IPv6

Product Segment

AX6000 ultimate AX performance: 1148+4804 Mbps

AX technology

Yes

Data Rate

• 802.11a : up to 54 Mbps
• 802.11b : up to 11 Mbps
• 802.11g : up to 54 Mbps
• 802.11n : up to 600 Mbps
• 802.11ac : up to 1000 Mbps
• 802.11ac : up to 4333 Mbps
• 802.11ax (2.4GHz) : up to 1148 Mbps
• 802.11ax (5GHz) : up to 4804 Mbps

Antenna

External antenna x 8

Transmit/Receive 2.4 GHz 4 x 4 5 GHz 8 x 8

Processor 2.2GHz quad-core processor

Memory 256 MB Flash, 1 GB RAM

Boosts speed

OFDMA (Orthogonal Frequency Division Multiple Access),

Beamforming: standard-based and universal, 1024-QAM high data rate, 20/40/80 MHz bandwidth,

Operating Frequency 2.4 GHz / 5 GHz

Ports

RJ45 for 10Gbps BaseT for WAN/LAN x 1, RJ45 for 1Gbps BaseT for LAN x 8, RJ45 for 1Gbps BaseT for WAN x 1

USB 3.1 Gen 1 x 2

SFP+ x 1

Button

WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button

LED Indicator

Power x 1

Wi-Fi x 3

WAN x 1

LAN x 1 10GE x 1

SFP+ x 1

Power Supply

• AC Input : 110V~240V(50~60Hz)
• DC Output : 19V 3.42A

Package content

RJ45 x1

Adapter x1

QSG x1

Warranty Card x1

RT-AX89X x1

Product Weight (g) 1280 g

AiMesh

• AiMesh:Yes
• Primary AiMesh router:Yes
• AiMesh node:Yes

Router APP

ASUS Router APP:Yes

Game

• Game Boost/acceleration:Yes
• WTFast:No

Alexa

Support Alexa skill:Yes

IFTTT

Support IFTTT:Yes

AiProtection

• AiProtection:AiProtection Pro
• Router Security Assessment:Yes
• Malicious site blocking:Yes
• Two-Way IPS:Yes

Infected Device Prevention and Blocking;Yes

Parental Control

• Parental Control:Yes
• Parental Control Customized Internet schedule:Yes

Traffic Control

• Adaptive QoS:Yes
• Bandwidth Monitor:Yes
• Bandwidth limiter:Yes
• Maximum Bandwidth limiter rule:32
• Traditional QoS:Yes
• Maximum Traditional QoS rule:32
• Traffic Monitor:Yes
• Real-time traffic monitor:Yes
• Wired Traffic Monitor:Yes
• Wireless Traffic Monitor:Yes
• Traffic Analyzer:Yes
• Traffic analysis period:Daily, Weekly, Monthly
• Website history:Yes

Wireless

• IPv6:Yes
• MU-MIMO:Yes
• Wi-Fi Encryption:WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support
• UTF-8 SSID:Yes
• Guest Network:Yes
• Maximum Guest Network rule:2.4GHz x2, 5GHz-1 x2,5GHz-2 x4
• Guest Network Encryption:Open system, WPA/WPA2-Personal
• WPS:Yes
• Wi-Fi MAC address filter:Yes
• Maximum MAC filters:64
• Wireless scheduler:Yes
• Airtime fairness:Yes
• RADIUS Server:Yes
• Universal beamforming:Yes
• Explicit beamforming:Yes

WAN

• Internet connection Type:PPPoE, PPTP, L2TP, Automatic IP, Static IP
• Dual WAN:Yes
• WAN Aggregation:Yes
• 3G/4G LTE dongle:Yes
• Android tethering:Yes
• Port forwarding:Yes
• Maximum port forwarding rule:64
• Port triggering:Yes
• Maximum port triggering rule:32
• DMZ:Yes
• DDNS:Yes
• NAT Passthrough:PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
• Let's Encrypt:Yes

LAN

• DHCP Server:Yes
• IGMP snooping:Yes
• IPTV:Yes
• LAN Link Aggregation:Yes
• Manually assign IP address:Yes
• Maximum manually assign IP address rule:64

VPN

• VPN Client L2PT:Yes
• VPN Client OVPN:Yes
• VPN Client PPTP:Yes
• VPN Server IPSec:Yes
• VPN Server OVPN:Yes
• VPN Server PPTP:Yes
• VPN Fusion:No

USB application

• File System:FS_Tuxera_HFS+,FS_Tuxera_NTFS,FS_Tuxera_vFAT,FS_ext2,FS_ext3,FS_ext4
• 3G/4G LTE dongle:Yes
• HDD hibernation:Yes
• Safely Remove disk:Yes
• AiCloud:Yes
• Download master:Yes
• AiDisk:Yes
• Media Server:Yes
• Time Machine:Yes
• Samba Server:Yes
• FTP Server:Yes
• Shared Folder privileges:Yes

Administration

• Operating mode:Accesspoint, AiMeshnode, Mediabridge, Repeater, Router
• Operating system:ASUSWRT
• Free OS upgrade:Yes
• Firewall:Yes
• Maximum Firewall keyword filter:64
• Maximum Firewall network service filter:32
• Maximum Firewall URL filter:64
• Wake on LAN (WOL):Yes
• SSH:Yes
• Configuration backup and restore:Yes
• Diagnosis tools:Yes
• Feedback system:Yes
• System log:Yes
